Modern Sliding Doors and Portals
Our System Offer
Sliding, lift-and-slide, or folding structures are system solutions made from aluminum profiles that perfectly combine a high level of operating comfort, thermal insulation, safety and modern design.
Reynaers Hi-Finity
Reynaers Hi-Finity is a unique warm sliding system with the thinnest aluminum profile.
This door, with its thin, barely visible profiles, creates the impression of a wall of clear glass expanding the boundaries of your house.
Even huge Reynaers Hi-Finity system sliding doors look elegant, light, airy and create a feeling of complete transparency.
The system provides various opening options: with two and three tracks, closing in the middle and in combination from two to six leaves.
Large glass leaves slide easily thanks to a roller mechanism at the bottom of the frame. For added convenience, Hi-Finity is equipped with a hidden electric drive that opens and closes the leaves with one press of a button.
Reynaers Hi-Finity system, allowing the installation of single- and double-glazed units, will provide high thermal insulation.
This door, with its thin, barely visible profiles, creates the impression of a wall of clear glass expanding the boundaries of your house.
Even huge Reynaers Hi-Finity system sliding doors look elegant, light, airy and create a feeling of complete transparency.
The system provides various opening options: with two and three tracks, closing in the middle and in combination from two to six leaves.
Large glass leaves slide easily thanks to a roller mechanism at the bottom of the frame. For added convenience, Hi-Finity is equipped with a hidden electric drive that opens and closes the leaves with one press of a button.
Reynaers Hi-Finity system, allowing the installation of single- and double-glazed units, will provide high thermal insulation.
Operational Characteristics
- Air Tightness – up to 600 Pa (Class 4)
- Burglary Resistance – class RC2
- Thermal Conductivity Coefficient – Ud ≥ 1.0 W/m2K (Single-chamber Glazed Unit); 0.7 W/m2K (Double-chamber Glazed Unit)
- Waterproof up to 600 Pa (Class 9A)
- Wind Load Resistance – B4
- Maximum Leaf Height – 3,500 mm
- Maximum Leaf Weight for Manual Opening – up to 1,200 kg
Hi-Finity
Corner Solution
Hi-Finity system corner solution allows doors to be opened at internal and external corners, while maintaining the system's benefits of excellent comfort and insulation level.
The video demonstrates the operation of the system with a corner solution and an electric drive.
The video demonstrates the operation of the system with a corner solution and an electric drive.
Hi-Finity
Reynaers Concept Patio 155
Reynaers CP 155 Lift-and-slide System is a first-class thermally insulated sliding door system. It is designed to create the largest possible glazed surfaces taking into account increased comfort. This system makes it possible to design exceptionally large doors with a single leaf weight of up to 300 kg (when using an electric drive of up to 400 kg).
CP155 corresponds to class 2 burglary protection confirming the security and reliability of the solution. This system is a universal solution for both low-storey suburban and multi-storey construction due to its excellent thermal characteristics and exceptional moisture, wind and sound resistance.
The size of one leaf can reach 2.7 meters in width and 3 meters in height. The maximum length of the structure and the number of tracks are not limited.
CP155 corresponds to class 2 burglary protection confirming the security and reliability of the solution. This system is a universal solution for both low-storey suburban and multi-storey construction due to its excellent thermal characteristics and exceptional moisture, wind and sound resistance.
The size of one leaf can reach 2.7 meters in width and 3 meters in height. The maximum length of the structure and the number of tracks are not limited.
Operational Characteristics
Sound Insulation – Rw (C; Ctr) less than 43 (-1; -5) dB,
Depending on the Type of Glazing Air Tightness – up to 600 Pa (Class 4)
Burglar Resistance – WK 2 (According to European Standard ENV 1627-1630)
Thermal Conductivity Coefficient – Uf ≥ 1.1 W/m2K, Depending on the Frame + Leaf Combination
Water Resistance – up to 900 Pa (Class E900)
Wind Load Resistance – up to 1,600 Pa (Class C4)
Corner Solution
CP 155 system corner solution allows doors to be opened at internal and external corners, while maintaining the benefits of the system such as comfort and insulation level.
An open corner can be used in CP 155 Monorails system and in the standard CP 155 2-rail system. A corner solution with fixed glass is available to provide optimum daylight transmission and transparency. A corner solution with fixed glass can only be used in CP 155 Monorails system.
All solutions have been tested at Reynaers Research Center (RAD) and guarantee a high level of air, wind and water resistance (3 – C2 – 7A).
An open corner can be used in CP 155 Monorails system and in the standard CP 155 2-rail system. A corner solution with fixed glass is available to provide optimum daylight transmission and transparency. A corner solution with fixed glass can only be used in CP 155 Monorails system.
All solutions have been tested at Reynaers Research Center (RAD) and guarantee a high level of air, wind and water resistance (3 – C2 – 7A).
Reynaers Concept Folding 77
Concept Folding® 77, folding door system, can be opened in different ways, both inwards and outwards.
CF 77 has an active leaf that is used as an entrance door when the rest of the structure is locked.
CF 77 system is compatible with all CS window and door systems and facades.
The external visible CF 77 profile is available in two style options: Functional and Slim Line (CF 77-SL).
The latter has a thinner and more aesthetic profile.
CF 77 has an active leaf that is used as an entrance door when the rest of the structure is locked.
CF 77 system is compatible with all CS window and door systems and facades.
The external visible CF 77 profile is available in two style options: Functional and Slim Line (CF 77-SL).
The latter has a thinner and more aesthetic profile.
Operational Characteristics
Sound Insulation – Class 2
Air Tightness – up to 600 Pa (Class 4)
Burglar Resistance – RC 2 (According to European Standard EN 1627-1630)
Water Resistance – Class 5A (200 Pa)
Wind Load Resistance – Class B2
Air Tightness – up to 600 Pa (Class 4)
Burglar Resistance – RC 2 (According to European Standard EN 1627-1630)
Water Resistance – Class 5A (200 Pa)
Wind Load Resistance – Class B2
Reynaers CF 77
Thanks to the 77 mm design depth, the system has excellent thermal characteristics: in the closed position up to 1.64 W/m2.
The thickness of a multiple glazed unit is 6-63 mm in the Functional design and 16-44 mm in the Slim Line design.
High-quality stainless steel rollers ensure free and silent movement of the leaves and can withstand long-term operating loads with a weight of each leaf of up to 120 kg.
Leaf stoppers perfectly hold a leaf in a stable position when opening the door, so that a leaf does not swing in a horizontal plane.
Reynaers CF 77 folding door can contain from 2 to 8 working leaves with a total width of up to 9.6 m.
Exclusive designs can reach larger sizes. The maximum leaf width of Reynaers CF 77 folding door structure is 1,200 mm, the maximum height is 3,000 mm. There are 22 types of openings available, and the leaves can be folded both outside and inside the room. An active leaf can function as a window or door.
The thickness of a multiple glazed unit is 6-63 mm in the Functional design and 16-44 mm in the Slim Line design.
High-quality stainless steel rollers ensure free and silent movement of the leaves and can withstand long-term operating loads with a weight of each leaf of up to 120 kg.
Leaf stoppers perfectly hold a leaf in a stable position when opening the door, so that a leaf does not swing in a horizontal plane.
Reynaers CF 77 folding door can contain from 2 to 8 working leaves with a total width of up to 9.6 m.
Exclusive designs can reach larger sizes. The maximum leaf width of Reynaers CF 77 folding door structure is 1,200 mm, the maximum height is 3,000 mm. There are 22 types of openings available, and the leaves can be folded both outside and inside the room. An active leaf can function as a window or door.
Color Range of the Profile System
We can offer interior and exterior profiles in almost any color you can imagine.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
We can offer interior and exterior profiles in almost any color you can imagine.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
We can offer interior and exterior profiles in almost any color you can imagine.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
We can offer interior and exterior profiles in almost any color you can imagine.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
There are over 450 different shades and finishes available: metallic or anodizing, matte or gloss RAL colors and even a special maintenance-free and scratch-resistant Coatex finish.
In addition, your windows can take on the appearance of a real wooden structure.
Important characteristics when choosing a multiple glazed unit
By combining types of coating, glass thicknesses and
distances between them, you can get rid of many problems
and increase the level of comfort.
distances between them, you can get rid of many problems
and increase the level of comfort.
The area of a multiple glazed unit makes up about 90% of the aluminum structure and largely affects its insulating properties.
Key parameters affecting the operational characteristics of a multiple glazed unit:
- glass thickness
- number of glasses
- coating and thickness of glass panels
- chamber filling
Key parameters affecting the operational characteristics of a multiple glazed unit:
- glass thickness
- number of glasses
- coating and thickness of glass panels
- chamber filling
Shall we discuss your project ?
We actively participate in projects as a technical consultant. We will help you design structures starting from the architectural decision stage.
